SAiMO CHECKWEIGHER
SERIES SCW-L
The SCW-L series checkweigher is suitable for large products
and their challenging application conditions. Its rugged design
combined with high accuracy load cells, can still deliver an
outstanding performance.
Saimo Checkweighers can provide your company with very accurate
in-line weight checking, helping you in reducing product giveaway
so your business can save money while performing quality control.
The SCW-L series comes in four standard models but we can custom
design for almost any application. Saimo Checkweighers are the
perfect tools for your production lines.
|
| FEATURES |
- Superb reliability and performance levels
- Advanced Digital Filtering algorithms for best performance.
- Rugged and fully sealed stainless steel construction.
- Hygienic design to ensure easy cleaning and minimize
product buildup.
- User friendly interface
- Large capacity product memory.
- Fast & easy product changeover.
- Comprehensive statistical package.
- Multi-language support
- Auto-zero function.
- Automatic belt speed adjustment.
- Factory networking capabilities
|
| BENEFITS |
- Perfect “cost savings” tool to reduce product giveaway
- Affordable quality control solution
- Easy operation
- Low maintenance requirement
|
| SPECIFICATIONS |
Model |
SCW-L10 |
SCW-L15 |
SCW-L25 |
SCW-L50 |
| Weight Range |
150g
to 10kg |
150g to 15kg |
300g to 25kg |
500g to 50kg |
| Accuracy |
± 5g |
± 7g |
± 10g |
± 15g |
| Max. Speed |
45 ppm |
45 ppm |
30 ppm |
30 ppm |
| Belt Length [mm] |
600, 800 |
600, 800 |
800, 1000, 1100 |
800, 1000, 1100 |
| Belt Width [mm] |
400, 500 |
400, 500 |
600, 650 |
600, 650 |
| Total Length [mm] |
700, 900 |
700, 900 |
890, 1090, 1190 |
890, 1090, 1190 |
| Line Height [mm] |
800 |
800 |
800 |
800 |
| Rejector Type |
Air Pusher |
As required |
As required |
As required |
|
| SUITABLE
APPLICATIONS |
 |
